    2000W 5520-4Z converter Ultrasonic Power Supply For Non woven Mask Making Machines

    Ask Lasest Price
    Brand Name : Altrasonic
    Model Number : HS-ASA-2000
    Certification : BV
    Price : negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 3,000 units per month
    Delivery Time : 7 working days after received your payment
    • Product Details
    • Company Profile

    2000W 5520-4Z converter Ultrasonic Power Supply For Non woven Mask Making Machines

    5520-4Z converter matched Ultrasonic Power Supply For Non-woven Mask Making Machines

    Description:

    The ultrasonic generator, also called ultrasonic driving power supply, electronic box, control box, is an important part of high power ultrasonic system. Main function is to generate high power and high frequency alternating current, drive the ultrasonic transducer. High-power ultrasonic power supply from the conversion efficiency into consideration generally take the form of switch power supply circuit.Ultrasonic power supply can be divided into self-excited and it excited type power supply, it power called ultrasonic generator excitation type, autonomous power called ultrasonic controller.

    Applications:

    Ultrasonic generator main function is to generate high power and high frequency alternating current, drive the ultrasonic transducer.
    Ultrasonic generator is applied to all kinds of ultrasonic equipment, mainly with ultrasonic welding, ultrasonic cutting, ultrasonic chemical equipment and ultrasonic welding equipment such as non-woven fabric.

    Specifications:

    ModelHS-ASA-2000
    Frequency20khz
    Output power2000watt
    Frequency tuning methodIntermittent
    Size410*600*180 mm
    Voltage220V 50/60HZ
    Net weight14kgs
    Temperature≤300℃
    Moisture

    ≤85%RH



    Competitive Advantage:

    ★ The use of high-quality electronic components assembly.
    ★ Advanced and reliable protection circuit makes the reliability is greatly improved.
    ★ FM and frequency automatic compensation, frequency of the digital display.
    ★ Frequency deviation, working current two meter indication and protection function.
    ★ According to the customer request interface plug.
    ★ Has the advantages of simple structure, easy to repair, cheap.

    Comparison:


    Analog generatorDigital generator
    CircuitAnalog circuit, discrete componentsDigital circuit, the chip control
    Automatic search×
    Automatic frequency tracking×
    Frequency adjustment range±0.15 KHz±0.5 KHz
    Power regulation×
    24 hours of continuous work×
    Non resonant condition×
    LCD×
    Add the PLC protocol×
    Automatic circuit protectionBad, easy to cause the damage of componentsGood
    Repair methodProfessional repair

    Module replacement


    5520-4Z converter matched Ultrasonic Power Supply For Non-woven Mask Making Machines
